Volumen
Laboratorio de calibración especializado en
Newark, New Jersey
Horarios de apertura
Lun
07:00 - 04:30
Mar
07:00 - 04:30
Mier
07:00 - 04:30
Juv
07:00 - 04:30
Vie
07:00 - 04:30
2 Mars Ct.
Boonton, NJ 07005
Boonton, NJ 07005
A2LA Cert #2553.01
ISO/IEC 17025
ANSI/NCSL Z540.1-1994
ANSI/NCSL Z540.3-2006
CAPACIDADES
Capacidades acreditadas
Capacidades trazables
Volumen
Química
Acelerometría
Dimensional
Electricidad
Fuerza
Humedad
Mass / Scale
Pressure / Vacuum
Temperatura
Par
Time / Frequency
Volumen
Volumen
Capacidades acreditadas
Global Calibration Scope
- Volumetric Instruments (Beakers, Volumetric Containers…): up to 20 000 mL
- Pipette: 0.1µL up to 1 000 mL
- Syringe: up to 200 mL
Common equipment serviced: Burettes, Flask, Syringe, Pipettes, Test tubes, Beakers, Dispenser, Tanks, Vessels, Gauge overflow, Gauge windows, Concrete air content meters, Level probes Pycnometers, Titrators
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Química
Química
Capacidades acreditadas
Global Calibration Scope
- Viscosity: kinematic and dynamic, consistometric cup, etc.
- Conductivity: Electrical (0 μS/cm to 200 mS/cm) and with Certified Reference Material (1,1 μS/cm to 111,3 mS/cm)
- Gas detector and Gas Concentration : Carbon monoxide, Nitrogen monoxide, Nitrogen dioxide, Oxygen, Total gaseous organic carbon, Dilution apparatus for olfactometry, Sulfur dioxide, Carbon dioxide, Hydrogen sulfide, Benzene, Methane, Ozone, Propane, etc.
- Refractometry: (1.33 ~ 1.62) nD (refractive index), 0 to 87.6% Brix, etc.
Common equipment serviced: Conductivity meters, Salinity meters, pH meters, Sucrose solutions, Gas detectors and gas concentration, Particle counters, Refractometry instruments, Viscosity instruments
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Acelerometría
Acelerometría
Capacidades acreditadas
Global Calibration Scope
- 100 mV/G Freq Response: 5 hz to 10 kHz
Common equipment serviced: Accelerometers
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Dimensional
Dimensional
Capacidades acreditadas
Global Calibration Scope
- Micrometers and Calipers up to 40 “
- Rulers up to 36”
- Height and depth gauges up to 40 “
- Pins and Dial Indicators up to 2 “
Common equipment serviced: Hand tools: Calipers, micrometers, indicators, height gauges, rulers & tapes
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Electricidad
Electricidad
Capacidades acreditadas
Global Calibration Scope
- AC/DC Voltage Generation up to 1100 V
- Measurements up to 160 kVdc and 100 kV ac.
- Electrical temp simulation: RTD, TC
- Current Generate up to 30 Amps/1025 A (w/ coil)
- Power (AC+DC) up to 30.8 kW
- Resistance 1 mOhm up to 10 TOhms
- Generate /measure signals up to 50 GHz.
- Absolute Power from -70 to +20 dBm.
- Phase Modulation up to 26.5 GHz.
- Phase Generate 0 to 90 º (up to 30 kHz)
- Phase measure 0 to 359.9 º (up to 500 kHz)
- Distortion 20 hZ to 26.5 GHz.
Common equipment serviced:
DC/LF: Multimeters, Oscilloscopes, LCR Meters, Oscilloscope/meter probes, Power supplies, Loads, Safety Testers, Resistance Meters, clamp meters, Hipots, panel meters, etc.
HF/RF/Microwave Signal Generators, Spectrum analyzers, power meters, function generators, power sensors, and Distortion analyzers
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Fuerza
Fuerza
Capacidades acreditadas
Global Calibration Scope
- Force gauges : up to 500 lbs class 6 & F weights
Common equipment serviced: Force gauges
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Humedad
Humedad
Capacidades acreditadas
Global Calibration Scope
- Generate: +/-1.4% RH from 10 to 90% RH
Common equipment serviced: RHT Meter/probes, psychrometers
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Mass / Scale
Mass / Scale
Capacidades acreditadas
Global Calibration Scope
- Scales: up to 500 lbs class 6 & F weights
- Balances up to 55 kG Class 1&3 Weights
Common equipment serviced: Balances, Scales
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Pressure / Vacuum
Pressure / Vacuum
Capacidades acreditadas
Global Calibration Scope
- Measure:Pneumatic -14.6 to 1000 psig
- Measure: Hydraulic: 10 to 10000 psig
Common equipment serviced: Calibrators, pressure gauges, sensors/transmitters, barometers, pressure sensors, manometers, Etc.
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Temperatura
Temperatura
Capacidades acreditadas
Global Calibration Scope
- Measuring range : -195 ºC to 420 ºC w/ SPRT
- Range of 35 to 500 ºC for IR Thermometers
Common equipment serviced: Temperature baths, chambers, ovens, calibrators, Temperature probes, IR thermometers
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Par
Par
Capacidades acreditadas
Global Calibration Scope
- 20 ozf-in to 200 ozf-in.
- 4 lbf-in to 600 lbf ft.
Common equipment serviced: Torque wrenches, screwdrivers, watches
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Time / Frequency
Time / Frequency
Capacidades acreditadas
Global Calibration Scope
- Measure and Generate frequencies up to 50 GHz
- Tachometers up to 100,000 RPM.
Common equipment serviced: Counters, Stopwatches, Timers, frequency generators, tachometers
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Química
Acelerometría
Global Calibration Scope
- 100 mV/G Freq Response: 5 hz to 10 kHz
Common equipment serviced: Accelerometers
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Dimensional
Global Calibration Scope
- Micrometers and Calipers up to 40 “
- Rulers up to 36”
- Height and depth gauges up to 40 “
- Pins and Dial Indicators up to 2 “
Common equipment serviced: Hand tools: Calipers, micrometers, indicators, height gauges, rulers & tapes
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Electricidad
Global Calibration Scope
- AC/DC Voltage Generation up to 1100 V
- Measurements up to 160 kVdc and 100 kV ac.
- Electrical temp simulation: RTD, TC
- Current Generate up to 30 Amps/1025 A (w/ coil)
- Power (AC+DC) up to 30.8 kW
- Resistance 1 mOhm up to 10 TOhms
- Generate /measure signals up to 50 GHz.
- Absolute Power from -70 to +20 dBm.
- Phase Modulation up to 26.5 GHz.
- Phase Generate 0 to 90 º (up to 30 kHz)
- Phase measure 0 to 359.9 º (up to 500 kHz)
- Distortion 20 hZ to 26.5 GHz.
Common equipment serviced:
DC/LF: Multimeters, Oscilloscopes, LCR Meters, Oscilloscope/meter probes, Power supplies, Loads, Safety Testers, Resistance Meters, clamp meters, Hipots, panel meters, etc.
HF/RF/Microwave Signal Generators, Spectrum analyzers, power meters, function generators, power sensors, and Distortion analyzers
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Fuerza
Global Calibration Scope
- Force gauges : up to 500 lbs class 6 & F weights
Common equipment serviced: Force gauges
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Humedad
Global Calibration Scope
- Generate: +/-1.4% RH from 10 to 90% RH
Common equipment serviced: RHT Meter/probes, psychrometers
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Masa / Escala
Global Calibration Scope
- Scales: up to 500 lbs class 6 & F weights
- Balances up to 55 kG Class 1&3 Weights
Common equipment serviced: Balances, Scales
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Presión / Vacío
Global Calibration Scope
- Measure:Pneumatic -14.6 to 1000 psig
- Measure: Hydraulic: 10 to 10000 psig
Common equipment serviced: Calibrators, pressure gauges, sensors/transmitters, barometers, pressure sensors, manometers, Etc.
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Temperatura
Global Calibration Scope
- Measuring range : -195 ºC to 420 ºC w/ SPRT
- Range of 35 to 500 ºC for IR Thermometers
Common equipment serviced: Temperature baths, chambers, ovens, calibrators, Temperature probes, IR thermometers
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Par
Global Calibration Scope
- 20 ozf-in to 200 ozf-in.
- 4 lbf-in to 600 lbf ft.
Common equipment serviced: Torque wrenches, screwdrivers, watches
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Tiempo / Frecuencia
Global Calibration Scope
- Measure and Generate frequencies up to 50 GHz
- Tachometers up to 100,000 RPM.
Common equipment serviced: Counters, Stopwatches, Timers, frequency generators, tachometers
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
